Nautos Bow Shackles are designed for applications where quick assembly of multiple connecting links is required. The shackle is cast and the pin is forged from AISI 316 stainless steel, with an electro-polished finish.
One shackle per pack.
Specification
| Size |
Pin diameter (mm) |
Shackle opening (mm) |
Shackle length (mm) |
| 4mm |
4 |
8 |
20 |
| 5mm |
5 |
10 |
25.5 |
| 6mm |
6 |
12 |
30 |
| 8mm |
8 |
16 |
41 |
| 10mm |
10 |
20 |
51 |
Additional sizes are available - please contact us if you would like us to order an option which is not currently in stock
